High Speed Pulp Molding Machine
Daily Capacity 1.3-15t with UL Certification.
|
Item |
Specification |
Remarks |
|
Normal operating rate of equipment |
95% |
24h / day * 95% = 23h |
|
Qualified yield |
95% |
The qualified goods include the product weight, appearance and performance conform to industry standard |
|
Product Weight Tolerance |
Within 1.5-5g |
Weight Tolerance is within 5% |
|
Daily output (23hours per day) |
1300-1500KGS |
Based on 9 inch plate in 16g |
|
Machine outer size |
7600*2700*3600mm |
|
|
Work Table Size |
1850 x 1850mm |
|
|
Machine weight |
20T |
|
|
Hot Press Type |
Hydraulic mode |
|
|
Hydraulic system |
Hydraulic maximum tonnage is 37T, max pressure is 20Mpa |
Hydraulic system electric motor is 5.5kw |
|
The max thermal power for the hot press mold |
280kw |
|
|
Motor (KW) |
5.5KW |
|
|
Installed Capacity |
7.25KW |
|
|
Forming mode |
Vacuum Suction Process |
|
|
The max product’s height |
≤100 mm |
|
|
Heating Way |
Electricity heating or oil heating |
|
|
Cycle Time（9inch plate, 15gram) |
≥50s(Oil Heating) ≥40s(Electric Heating) |
|
|
Material |
Aluminum Alloy 6061 |
|
|
Programmable control unit |
PLC |
SIEMENS brand |
|
Color touch control screen (human machine interface) |
12inch |
SIEMENS brand |
