Regular Speed Pulp Molding Machine
Daily Capacity 650-750kgs.
|
Item |
Specification |
Remarks |
|
Normal operating rate of equipment |
95% |
24h / day * 95% = 23h |
|
Qualified yield |
95% |
The qualified goods include the product weight, appearance and performance conform to industry standard |
|
Product Weight Tolerance |
Within 1.5-5g |
Weight Tolerance is within 5% |
|
Daily output (22hours per day) |
Oil Heating: 620~670kgs Electric Heating: 737~811kgs |
Based on 9 inch plate weight in 16g |
|
Machine outer size |
5700*2600*4100mm |
|
|
Work Table Size |
1200 x 1050mm |
|
|
Machine weight |
18T |
|
|
Hot Press Type |
Hydraulic mode |
|
|
Hydraulic system |
Hydraulic maximum tonnage is 37T, max pressure is 20Mpa |
Hydraulic system electric motor is 5.5kw |
|
The max thermal power for the hot press mold |
190kw |
|
|
Motor (KW) |
5.5KW（oil Heating） 210KW(Electric Heating） |
|
|
Installed Capacity |
5.5KW（oil Heating） 210KW(Electric Heating） |
|
|
Forming mode |
Vacuum Suction Process |
|
|
The max product’s height |
≤150 mm |
|
|
Heating Way |
Electricity heating or oil heating |
|
|
Cycle Time（9inch plate, 15gram) |
60~65s(Oil Heating) 50-55s(Electric Heating) |
The mold is quoted according to the plate product, if the product depth exceeds 2.5mm, the mold cost increased by 20%. |
|
Material |
Aluminum Alloy 6061 |
|
|
Programmable control unit |
PLC |
SIEMENS brand |
|
Color touch control screen (human machine interface) |
10inch |
SIEMENS brand |
